MEAN WELL introduce the new high performance product family of HRP Series, to comply with the energy saving trend, with high operating efficiency and low no load power consumption. HRP(G)-150 are 150W AC/DC miniture enclosed type power supplies with PFC function that fulfil the requirement of EN61000-3-2 for harmonic current. Compared to our first generation enclosed type PFC product SP-150 Series, HRP(G)-150 is reduced in size by 40.5% whilst the working efficiency has increased by 5~13%. Featureing up to 89% high efficiency, it can provide 150W continuously at up to 50°C using only free air convection.

Standard functions of HRP-150 and HRPG-150 include 300VAC input surge immunity for 5 seconds, remote sense, LED indicator, heavy industry level of EMS immunity (EN61000-6-2) and protection for short circuit, overload (constant current limiting), over voltage and over temperature. To filfil the emerging trend of eco-design MEAN WELL offers the HRPG-150 models with additional remote ON/OFF control and 5V/0.3A standby output to acheive the goal of no load power consumption <0.5W. More and more end systems ask for this feature to comply with the requirement of Energy Star and EuP norms and using our HRPG-150 should help designers achieve those regulations easily!

Suitable applications of HRP(G)-150 are general electronic application, factory automation, moving sign, test and measurement equipment, and all usage that requires low no load power consumption.

For more information on the RPS/D/T-160 Series or other products within this range please speak with a member of our sales team on +44 (0)118 970 3858, review the full specification below or visit our Enclosed Power Supplies section.

HRP-150 Series Specification
HRPG-150 Series Specification
