After the launched products of MSP-100, MSP-200, MSP-300 and MSP-450 series, MEAN WELL further introduced the 600W AC/DC medical enclosed type power supply~MSP-600 series, in response to the high wattage requirement of reliable medical power supplies. MSP-600 series comply with international medical safety regulations (MOOP level) and feature with low leakage current (less than or equal to 300μA at 264VAC), hence, they are good power solutions for non-patient contact medical applications. These units also possess no load power consumption less than 0.8W, 5 years warranty, and EMI Class B level compliance, therefore, they can be used in all kinds of “green mode” medical equipments or electric devices and fulfill the energy-saving requirements for end systems.

Featuring with 85~264VAC universal AC input, MSP-600 provides 3.3V~48V output voltage options and possesses up to 89% of high efficiency. It can be forced air cooling by built-in DC fan for full load operation at -40°C~+50°C ambient temperature, and even up to +70°C by suitable derating. Other standard functions include protections for short circuit, overload, over voltage, and over temperature, 300VAC input surge immunity for 5 seconds, remote ON/OFF control, remote sense, fan ON/OFF control, and DC OK signal output. In addition, to meet the requirement of higher wattage application, the models of MSP-600-24/36/48 equipped with parallel function and can be operated up to 4 units in parallel. MSP-600 series comply with global medical certificates per UL/ CUL/ CB/ CE that greatly ensure users’ safety. Suitable applications include medical equipments requiring low leakage current, chemical or biological detection equipments, analysis facilities, and any systems requiring low no load power consumption.

  • Low leakage current less than 300μA @ 264VAC
  • No load power consumption less than 0.8W
  • Universal AC input 85~264V
  • Built-in active PFC function, PF greater than 0.94
  • Withstand 300VAC surge for 5 seconds
  • High efficiency up to 89%
  • Dimming range: 1~100%
  • Protection: Short circuit / Overload / Over voltage / Over temperature
  • Built-in constant current limiting circuit
  • Built-in remote sense function
  • DC OK signal
  • Long life DC fan with fan ON/OFF control function
  • Built-in remote ON/OFF control & 5V/0.3A standby output
  • Parallel function for MSP-600-24/36/48
  • Certificate: UL / CUL / CB / CE
  • Dimension(LxWxH): 218x 105x 63.5mm
  • 5 years warranty

Our range of 600W Enclosed Type Medical Power Supplies can be found here 600W Enclosed Type Medical Power Supply
