120W High Efficiency Slim DIN Rail Power Supply with PFC Function
To add to available high performance single output slim DIN rail series MEAN WELL have launched a lower wattage product, SDR-120 Series, for the growing demand of low to medium wattage applications with high performance and space saving requirements. These series are AC/DC isolation Class I power supplies.
SDR-120 Series possesses up to 91% of high efficiency and can provide 120W continuously or 180W of peak power for 3 seconds at temperatures up to 55 ~ 60C, using only free air convection. With built in active PFC function SDR-120 are full range AC input din rail power supplies that fulfil the requirements of EN61000-3-2 for harmonic current. The slim design also helps to save space when installed.
Other standard functions include DC OK relay contact, on panel LED indicator, and protection for short-circuit, overload (constant current limiting, shut down if over 3 seconds), over voltage, and over temperature. To fulfil the requirements of marine and semi-conductor related usage SDR-120 also complies with GL and SEMI F47 norms in addition to UL, CUL, TUV, and CE certificates. Suitable applications are factory automation, semi-conductor fabrication equipment, marine related installation, and electro-mechanical applications.
For more information on the Series or other products within the range please speak with a member of our sales team on +44 (0)118 970 3858, review the full specifications below or visit our Din Rail Power Supply section.
