A300-1K0 Series - 1000W Modified Sine Wave DC-AC Power Inverter



A300-1K0 series is a modified sine wave DC/AC inverter that can provide 1000W continuously and possesses 1200W for up to 30 minutes and 2400W of surge peak load capability. Protections for this unit include battery low alarm, battery low shutdown, battery polarity, battery over voltage protections for input side; short circuit, inverter overload, and over temperature protections for output side. A300-1K0 series is suitable for powering many kinds of consumer electronics, home appliances, power tools, office & portable equipment and lighting equipment in vehicles, yachts, and mobile homes.

Additional information


Mean Well Enterprises Ltd.


CE, E13






DC to AC Mains Power

  • 12V or 24V DC input
  • Power ON-OFF switch
  • Input voltage range: -15% ~ +25%
  • Output voltage regulation: ±10%
  • Bat. Low alarm/Bat. Low shutdown/Over voltage/Over temp./Output short/Input polarity reverse/Over load protections
  • Output waveform: Modified sine wave
  • Cooling fan ON-OFF control
  • Topology: Microprocessor
  • Approvals: e13/ CE
  • Consumer electronics
  • Home appliances
  • Power tools
  • Office equipment
  • Portable equipment
  • Lighting equipment in vehicles, yachts, and mobile homes
Output Voltage230Vac
Rated Output Power1000W
Output Peak Power1200W<30 min.
Output Surge Power2400W
WaveformModified Sine Wave
Frequency50Hz ±1%
LED IndicatorGreen LED for power on; Yellow LED for O.T.P.; Red LED for power failure status
Over Load Protection>1200W shut down o/p voltage, re-power on to recover
Over Temperature Protection60±5°C/ 140±9°F
Output Short ProtectionShut-off
Reverse Polarity ProtectionBy fuse open
Working Temperature0°C ~ +30°C @100% load, 40°C @ 50% load
Working Humidity20% ~ 90% RH non-condensing
Storage Temperature/Humidity-30°C ~ +70°C/ -22 ~ +158°F, 10 ~ 95% RH
Temperature Coefficient±0.05% /°C (0 ~ 50°C)
Isolation ResistanceI/P-O/P:100M Ohms min./ 500VDC/ 25°C/ 70% RH
EMI Condiction & RadiationCompliance to EN55022 class B, 72/ 245/ CEE, 2006/96/CE
EMS ImmunityCompliance to EN61000-4-2,3
LVDCompliance to EN60950
Cooling>40°C (NTC) fan on
Standard Output RecepticalUniversal (F4), European & USA Versions also available
Input DC Connector1000mm Cable terminated with 10.6mm Ring terminals
MTBF98Khrs min. MIL-HDBK-217F (25°C)
