Description
PD-25 Series is a range of Dual output open frame switching power supplies designed with short circuit, over load, over voltage and over temperature protections. PD-25 are a highly reliable range of open frame power supplies with low leakage current and free air convection cooling.
Additional information
Standards | CB, CE, CSUUS, TUV |
---|---|
Type | AC/DC |
Outputs | Dual |
- International AC input range
- Low leakage current <0.5mA
- Short circuit, over voltage, overload & over temperature protection
- 100% full burn-in test
- Fixed switching frequency at 100KHZ
- Cooling by free air convection
- CB
- CE
- CSUUS
- TUV
Products in this range
Part number | Power (watts) | Voltage (max/rated) | Current (amps) | R&N (mV) | Efficiency (%) | |
---|---|---|---|---|---|---|
PD-2505 | 25W | 5V | 3A | 50mV | 73% | Request Quote |
PD-2512 | 24W | 12V | 1A | 50mV | 74% | Request Quote |
PD-2515 | 24W | 15V | 1A | 50mV | 75% | Request Quote |
PD-25A | 25W | 12V | 1A | 150mV | 71% | Request Quote |
PD-25B | 25W | 24V | 1A | 200mV | 77% | Request Quote |
