IDPV-65 Series - IDPV-65 series 65W PWM Output LED Driver

IDPV-65 series is a 65W PWM Output LED Driver.
SKU: IDPV-65 Series
Categories: LED Power Supply, Open Frame Switching Power Supply
Description
IDPV-65 series is a 65W PCB type AC/DC LED driver featuring a constant voltage mode PWM style output design. IDPV-65 operates from 180~295VAC and offers models with different rated voltage ranging between 12V and 60V. Thanks to high efficiency up to 90% and a fan-less design the entire series is able to operate between -20c to +40c ambient temperature under free air convection. IDPV-65 is equipped with various function options such as dimming methodologies which provide the design flexibility for an LED lighting system.
Additional information
Weight | 0.15 kg |
---|---|
Inputs | 180 ~ 295VAC |
Type | AC/DC,Constant Voltage,LED Driver |
Range Power |
- Constant Voltage PWM style output with frequency 1KHz
- PCB Type design
- Built-in active PFC function
- No load power consumption <0.5W (Blank-Type)
- Function options: 2 in 1 dimming (dim-to-off);Auxiliary DC output
- 3 years warranty
- LED strip lighting
- Indoor LED lighting
- LED decorative lighting
- LED architecture lighting
Products in this range
Part number | Power (watts) | Voltage (max/rated) | Current (amps) | Efficiency (%) | |
---|---|---|---|---|---|
IDPV-65-12 | 50.4W | 12VDC | 4.2A | 85% | Request Quote |
IDPV-65-24 | 57.6W | 24VDC | 2.4A | 87% | Request Quote |
IDPV-65-36 | 64.8W | 36VDC | 1.8A | 88% | Request Quote |
IDPV-65-48 | 64.8W | 48VDC | 1.35A | 89% | Request Quote |
IDPV-65-60 | 64.8W | 60VDC | 1.08A | 90% | Request Quote |
