TDR-240-48 - TDR-240-48 48V 240W Slim Three Phase Industrial DIN Rail with PFC Function
48V 240W Slim Three Phase Industrial DIN Rail with PFC Function
Description
TDR-240-48 is an economical slim 240W Din Rail power supply series, adapted to be installed on TS-35/7.5 or TS-35/15 mounting rails.The body is designed 63mm in width, which allows space saving inside the cabinets. The entire series adopts the full range AC input from 3 ψ 340VAC to 550VAC (Dual Phase operation possible) and conforms to EN61000-3-2, the norm the European Union regulates for harmonic current.TDR-240-48 is designed with metal housing that enhances the unit’s power dissipation. With working efficiency up to 92%, the entire series can operate at the ambient temperature between -30°C and 70°C under air convection. It is equipped with constant current mode for over-load protection, fitting various inductive or capacitive applications. The complete protection functions and relevant certificates for industrial control apparatus make TDR-240-48 a very competitive power supply solution for industrial applications. For more information and to discuss your requirements, please contact us.
Additional information
| Weight | 1.00 kg |
|---|---|
| Current (amps) | 5A |
| Efficiency (%) | 92% |
| Function | DC OK Signal |
| Inputs | 340 ~ 550VAC |
| Power (watts) | 240W |
| R&N (mV) | 120mV |
| Standards | AS/NZS61558-1/-2-16,BS/EN61558,CE,EAC TP TC 004,UKCA,UL61010 |
| Type | AC/DC,Din-Rail,Industrial |
| Voltage (max/rated) | 48VDC |
| Range Power | |
| Outputs | Single |
| warranty |
- Three phase 340 ~ 550VAC wide range input (Dual phase operation possible)
- Built-in passive PFC function
- Short circuit, over load, over voltage, over temperature protections
- Built-in constant current limiting circuit
- DC OK Relay contact
- Industrial control system
- Semiconductor fabrication equipment
- Factory automation
- Electro-mechanical apparatus
