DRA-60 Series - 60W Single Output Switching Power Supply

Email

Description

DRA-60 Series DIN rail power supplies comprise of two models, providing 12 Vdc and 24 Vdc outputs with output current adjustment. The current adjustment function is a 3 in 1 dimming function which allows the output current to be adjusted via a 1 – 10 Vdc, variable resistance or PWM signal. The power supplies can be mounted on TS-35/7.5 or TS-35/15 DIN rails, and have a full range 90 – 264Vac input. With a working efficiency of up to 87%, DRA-60 Series can work in ambient temperatures from -30°C to +70°C using only air convection cooling; at only 40 mm wide these units are also suited to limited space applications. DRA-60 Series also have short circuit protection, overload protection, over voltage protection and front panel DC voltage adjustment. The products carry UL, CUL, CB, TUV & CE safety certification and meet the requirement of IEC60950-1 Limited Power Source (LPS).

Additional information

Manufacturer

Mean Well Enterprises Ltd.

Standards

CB, CE, CURUS, TUV Certified

Type

AC/DC

Outputs

Single

Technology

Switchmode

Inputs

90~264Vac

  • Universal AC input range
  • Built in 3 in dimming function (1-10Vdc, PWM signal or resistive)
  • Can be installed on DIN rail TS-35/7.5 or 15
  • LED indicator for power on
  • Cooling by free air convection
  • 3 years warranty
  • Machine vision inspection system
  • Plant cultivation system
  • CB
  • CE
  • CURUS
  • TUV Certified
