DRDN20-12 - DRDN20-12 20A 12VDC Din Rail Type Redundancy Module

DRDN20-12 20A 12VDC Din Rail Type Redundancy Module

Email

Description

DRDN20-12 20A 12VDC Din Rail Type Redundancy Module

Additional information

Weight 0.30 kg
Current (amps)

20A

Efficiency (%)

98%

Function

1+1 Redundancy,1+N Redundancy

Inputs

12VDC

Type

Din-Rail,Redundant,DC/DC

Outputs

Single

  • Supports 1+1 and N+1 redundancy system
  • 2 channel input and 1 output
  • Suitable for redundancy operation of 12V/24V/48V system
  • Output current up to 20A
  • Cooling by free air convection
  • -40°C ~ +80°C ultra-wide operating temperature (>+60°C derating)
  • 32mm slim width
  • Built-in 2 channels DC OK signal and alarm relay contact
  • Installed on DIN Rail TS35/7.5 or 15
  • 3 yeas warranty
  • Industrial control system
  • Semiconductor fabrication equipment
  • Factory automation
  • Electro-mechanical apparatus
