MEAN WELL Products
Additional information
| Weight | 0.02 kg |
|---|---|
| Current (amps) | 600mA |
| Inputs | 18 ~ 75VDC |
| Power (watts) | 3W |
| Technology | 2xMOPP |
| Type | DC/DC,Medical Grade,Module Type |
| Voltage (max/rated) | 5VDC |
| Range Power | |
| Outputs | Single |
| warranty |
DIP 24 package with international standard pinout
4:1 wide input range
Low patient leakage current <5?A
Wide operating temperature range -40 ~ +90°C
2xMOPP Medical safety approved according to IEC60601-1
Short circuit (Continuous), Over load protections
6KVDC or 4.2KVAC high I/O isolation (Reinforced isolation)
3 years warranty
Medical devices
Medical oxygen monitors
CT scanning
Medical carts
Oral care equipment
Industrial control systems
