SCW05A-05 - 5W DC-DC Regulated Single Output Converter
SCW05A-05 is a 5W DC-DC Regulated Single Output Converter
SKU: SCW05A-05
Categories: DC-DC Converters, Uncategorized
Category: DC-DC ConvertersSwitching Power Supply
Additional information
Weight | 0.02 kg |
---|---|
Current (amps) | 200~1000mA |
Efficiency (%) | 75% |
Power (watts) | 5W |
R&N (mV) | 50mV |
Type | DC/DC |
Voltage (max/rated) | 5V |
Range Power |
- 2:1 wide input range
- 4:1 wide input range (optional)
- 1000VDC I/O isolation
- Input Pi network filter
- Protections:Short circuit/Over load
- Free air convection
- Five-sided shield metal case
- High reliabilty/low cost
- 100% burn-in test
- SCWN06A-05
Products in this range
Part number | Power (watts) | Voltage (max/rated) | Current (amps) | R&N (mV) | Efficiency (%) | |
---|---|---|---|---|---|---|
SCW05A-05 | 5W | 5V | 200~1000mA | 50mV | 75% | Request Quote |
SCW05A-09 | 5W | 9V | 111~556mA | 60mV | 80% | Request Quote |
SCW05A-12 | 6W | 12V | 94~470mA | 60mV | 80% | Request Quote |
SCW05A-15 | 6W | 15V | 80~400mA | 60mV | 81% | Request Quote |
SCW05B-05 | 5W | 5V | 200~1000mA | 50mV | 77% | Request Quote |
SCW05B-09 | 5W | 9V | 111~556mA | 60mV | 81% | Request Quote |
SCW05B-12 | 6W | 12V | 94~470mA | 60mV | 82% | Request Quote |
SCW05B-15 | 6W | 15V | 80~400mA | 60mV | 83% | Request Quote |
SCW05C-05 | 5W | 5V | 200~1000mA | 50mV | 77% | Request Quote |
SCW05C-09 | 5W | 9V | 111~556mA | 60mV | 83% | Request Quote |
SCW05C-12 | 6W | 12V | 94~470mA | 60mV | 83% | Request Quote |
SCW05C-15 | 6W | 15V | 80~400mA | 60mV | 85% | Request Quote |
