RCP-CMU - 1U Rack Control and Monitoring Unit

Email

Description

RCP-CMU-1 is a fully digitalized control/monitoring unit for the RCP-2000 power system that up to 32 RCP-2000 units can be handled by one RCP-CMU-1. Equipped with USB, RS-232 and ethernet interface, it can be connected locally to PC or remotely via GSM modem to execute the control and monitoring tasks. With built in 4 configurable relay contacts, users can flexibly monitor specific events or alarms and react with the suitable action accordingly.

Additional information

Manufacturer

Mean Well Enterprises Ltd.

Standards

CB, CE, CSUUS, TUV

  • 1U low profile/19-inch rack mounting
  • Control and monitor up to 32 RCP-2000 units
  • Front panel LCD and buttons for on-site service without PC
  • USB, RS-232 or ethernet interface for PC connection locally or remote monitoring and control via GSM modem
  • Alarm/event log with time and date
  • Windows-based PC communication software
  • Easy wire connections on rear side
  • 4 user programmable relay outputs for traditional remote monitoring warning
Digital MeterDisplay the DC output vol, current and temp.
LED IndicatorGreen: Power on Red:Alarm
Relay Contact4 user programmable relay
Voltage Range10~60VDC
Input Current0.5A/24VDC 0.25/48VDC
Working Temperature-25~+70°C
Working Humidity20~90% RH non-condensing
Storage Temp. Humidity-40~+85°C, 10~95% RH
Vibration10~500Hz, 2G 10min./1 cycle, 60 min. each along X, Y, Z axes
Safety StandardsUL60950-1; TUV EN60950-1 Approved
EMCCompliance to EN55022; EN61000-4-2,3,4,6,8
  • CB
  • CE
  • CSUUS
  • TUV
