GSM06U series - 6W AC-DC Single Output Medical Power Adaptor Series

The GSM06U is a 6W single-output medical power adaptor series. This product is equipped with a 2-Pin standard USA AC power plug and input range of 85V DC to 264V DC.

Email

Description

The GSM06U is a 6W single-output medical power adaptor series. This product is equipped with a 2-Pin standard USA AC power plug and input range of 85V DC to 264V DC.
The series supplies different models with output voltages ranging between 5V DC and 24V DC that can satisfy the demands for various kinds of small medical devices. With an efficiency of up to 82% and an extremely low no-load power consumption of below 0.03W, the GSM06U series is compliant with USA EISA 2007 and approved with international medical safety certificates. The supreme feature allows the adaptor to save energy when is either under the operating mode or the standby mode. The entire series utilises the 94V – 0 flame retardant plastic case, providing the double insulation that effectively prevents electrical shock.

Additional information

Inputs

120 ~ 370VDC,85 ~ 264VAC

Plug

USA 2 Pin

Power (watts)

6W

Standards

ANSI/AAMI ES60601-1(3.1 version)

Technology

Level V

Type

AC/DC,Medical Grade,Plugtop

Range Power

Outputs

Single

Blood glucose meter
Bloof pressure meter
Nebuliser
Inhaler
Portable medical device

  • ANSI/AAMI ES60601-1(3.1 version)
