PM-15 Series - 15W Single Output Encapsulated Medical Switching Power Supply

Email

Description

Featuring class II isolation levels they can be equiped into non-patient contact medical equipment and still comply with class B as per EMI regulations. With energy saving and the environment in mind the no load power consumption is lower than 0.5W so that it complies with the requirements for “green mode” power supplies. Standard functions include short circuit, over load and over voltage protections. Suitable for use in general medical or for industrial usage that require low leakage current, general electronic applications and low profile IT equipment these on-board type PSU’s can be applied on the main control PCB of the final systems.

Additional information

Manufacturer

Mean Well Enterprises Ltd.

Standards

CB, CE, CSUUS, MEDICAL, TUVMedical

Type

AC/DC

Outputs

Single

  • Universal AC input/full range
  • Ultra low profile
  • Isolation class II
  • No load power consumption <0.5W
  • Short circuit, over load, over voltage protections
  • UL60601-1, IEC60601-1 & TUV EN60601-1 medical safety approved
  • Cooling by free air convection
  • Fixed switching frequency at 67KHz
  • Non-patient contact medical
  • General electronics
  • IT equipment
  • Industrial
Input Voltage85 ~ 264VAC 120 ~ 370VDC
Input Frequency47 ~ 440Hz
AC Current0.35A/115VAC 0.2A/230VAC
Inrush Current30A/115VAC 50A/230VAC typically, cold start
Setup, Rise Time1000ms, 20ms/230VAC 1000ms, 20ms/115VAC at full load
Holdup Time100ms/230VAC 24ms/115VAC typically at full load
Overload ProtectionAbove 105% rated output power
Hiccup mode, recovers automatically after fault condition is removed
Over Voltage ProtectionShut off o/p voltage, clamping by zener diode
Working Temperature-20°C to +70°C (Refer to output load derating curve)
Working Humidity20 ~ 90% RH non-condensing
Storage Temperature, Humidity-40°C to +85°C, 10 to 95% RH
Temp Coefficient±0.03%/°C (0 ~ 50°C)
Vibration10 ~ 500Hz, 2G 10min./1cycle, Period for 60min.each along X, Y, Z axes
Satety StandardsUL60950-1, UL60601-1,TUV EN60601-1, IEC60601-1 Approved
Withstand VoltageI/P-O/P:4KVAC
Isolation ResistanceI/P-O/P:100M Ohms/500VDC/25°C/70% RH
EMCCompliance to EN55011(CISPR11), EN55022 (CISPR22) Class B, EN61000-3-2,-3
EN61000-4-2,3,4,5,6,8,11; ENV50204, EN55024, EN60601-1-2, EN61204-3 Medical level, criteria A.
MTBF499.7Khrs min. MIL-HDBK-217F (25°C)
Dimensions75 x 53 x 22.7mm
