OWA-90E Series - OWA-90E Series 90W Single Output Waterproof Switching Adaptor
SKU: OWA-90E Series
Categories: Desktop Adaptor, Enclosed Switching Power Supply, LED Power Supply, Switching Power Supply
Description
OWA-90E is a 90W class II single output external power supply series with waterproof feature. The fully potted silicone inside the plastic enclosure enhances the heat dissipation; it also achieves the IP67 level so that the unit can be used in damp, humid or dusty environments. The no load power consumption is less than 0.15W, to fulfil European energy saving requirements, and is suitable for EN60335 applications, such as household appliances.
Additional information
Inputs | 90 ~ 135VAC |
---|---|
Plug | EURO 2 Pin |
Standards | Double Insulation |
Technology | Active PFC,Level VI |
Type | AC/DC,LED Driver |
Range Power | |
Outputs | Single |
- Double Insulation
Products in this range
Part number | Power (watts) | Voltage (max/rated) | Current (amps) | R&N (mV) | Efficiency (%) | |
---|---|---|---|---|---|---|
OWA-90E-12 | 90W | 12VDC | 8A | 150mV | 89% | Request Quote |
OWA-90U-15-E | 90W | 15V | 6A | 150mV | 89% | Request Quote |
OWA-90U-20-E | 90W | 20V | 5A | 150mV | 89% | Request Quote |
OWA-90U-24-E | 90W | 24V | 4A | 150mV | 89% | Request Quote |
OWA-90U-30-E | 90W | 30V | 3A | 200mV | 89% | Request Quote |
OWA-90U-36-E | 90W | 36V | 3A | 200mV | 90% | Request Quote |
OWA-90U-42-E | 90W | 42V | 2A | 250mV | 90% | Request Quote |
OWA-90U-48-E | 90W | 48V | 2A | 250mV | 90% | Request Quote |
OWA-90U-54-E | 90W | 54V | 2A | 350mV | 90% | Request Quote |
