HLG-600H-B Series - 600W Single Output Dimming Function Switching Power Supply
Description
HLG-600H-B series is a high performance dustproof and waterproof AC-to-DC LED power supply with power up to 600Watts and three in one dimming function. The fully-potted silicone and aluminium case facilitate heat dissipation allowing the fanless design and helping to deliver efficiency up to 96%, topping that of others in the LED power supply field. Other features include wide working temperature range between -40 and +70, adjustable output voltage and current, EN61000-4-5 compliant surge susceptibility up to 4KV, <0.5Watt low no-load power consumption at remote OFF and the ability to work at 277VAC input. These attributes all make HLG-600H-B fit for indoor/outdoor LED lighting applications requiring remarkable reliability and dimming capabilities.
Additional information
Standards | CB, CE, CSUUS, PFC, TUV PSE, Independent from Luminaire, IP67 Rated, SELV, Short Circuit Proof, Suitable for mounting on flammable surface, Suitable for mounting on wood |
---|---|
Type | AC/DC |
Outputs | |
Technology | Switchmode |
Inputs | 90~305Vac |
IP rating | IP67 |
Function | Dimmable |
- Universal AC input / Full range (up to 305VAC)
- Built-in active PFC functio
- No load power consumption <0.5W at remote OF
- High efficiency up to 96%
- -40℃ ~ +70℃ wide operating range
- Short circuit, over current, over voltage & over temperature protections
- Fanless design, cooling by free air convection
- IP67 design for indoor or outdoor installations
- Withstand 5G vibration test
- Three in one dimming function - 0~10Vdc or PWM signal or resistive
- Suitable for dry, damp or wet location
- 5 years warranty on approved installs
- LED street lighting
- LED Highbay lighting
- Parking space lighting
- LED searchlight
- LED fishing lamp
- CB
- CE
- CSUUS
- Independent from Luminaire
- IP67 Rated
- PFC
- SELV
- Short Circuit Proof
- Suitable for mounting on flammable surface
- Suitable for mounting on wood
- TUV PSE
Products in this range
Part number | Power (watts) | Voltage (max/rated) | Current (amps) | R&N (mV) | Efficiency (%) | |
---|---|---|---|---|---|---|
HLG-600H-12B | 480W | 12V | 40A | 150mV | 92% | Request Quote |
HLG-600H-15B | 540W | 15V | 36A | 150mV | 94% | Request Quote |
HLG-600H-20B | 560W | 20V | 28A | 150mV | 95% | Request Quote |
HLG-600H-24B | 600W | 24V | 25A | 150mV | 95% | Request Quote |
HLG-600H-30B | 600W | 30V | 20A | 200mV | 95% | Request Quote |
HLG-600H-36B | 601W | 36V | 17A | 250mV | 96% | Request Quote |
HLG-600H-42B | 601W | 42V | 14A | 250mV | 96% | Request Quote |
HLG-600H-48B | 600W | 48V | 13A | 250mV | 96% | Request Quote |
HLG-600H-54B | 605W | 54V | 11A | 350mV | 96% | Request Quote |
