HomeMEAN WELL ProductsLED Power SupplyPLN-100-27 95.85W 27V 3.55A IP64 Rated Constant Voltage PFC LED Lighting Power Supply
PLN-100-27 95.85W 27V 3.55A IP64 Rated Constant Voltage PFC LED Lighting Power Supply

PLN-100-27 - PLN-100-27 95.85W 27V 3.55A IP64 Rated Constant Voltage PFC LED Lighting Power Supply

95.85W 27V 3.55A IP64 Rated Constant Voltage PFC LED Lighting Power Supply

Email
SKU: PLN-100-27 Category: Category:

Description

PLN-100 is a led lighting power unit with active PFC function for LED lighting applications. This limited power soruce complies with UL1310 Class II and has a high IP level design at IP64, protecting the components from dust and moisture damage and making it useable for indoor and outdoor applications requiring low levels of waterproofing.

Additional information

Weight 0.58 kg
Current (amps)

4A
Efficiency (%)

87%
Power (watts)

96W
R&N (mV)

150mV
Type

AC/DC,Constant Voltage,LED Driver
Voltage (max/rated)

27VDC
Range Power

Outputs

Single

Products in this range

Part number Power (watts) Voltage (max/rated) Current (amps) R&N (mV) Efficiency (%)
PLN-100-12 60W 12VDC 5A 150mV 83% Request Quote
PLN-100-15 75W 15VDC 5A 150mV 85% Request Quote
PLN-100-20 96W 20VDC 5A 150mV 87% Request Quote
PLN-100-24 96W 24VDC 4A 150mV 87% Request Quote
PLN-100-27 96W 27VDC 4A 150mV 87% Request Quote
PLN-100-36 95W 36VDC 3A 150mV 87% Request Quote
PLN-100-48 96W 48VDC 2A 200mV 87% Request Quote
