ELG-200-48 - 199.68W 48V 4.16A Constant Voltage & Constant current LED Driver

Email

Description

ELG-200-48 is a 199.68W 48V 4.16A AC/DC LED driver featuring dual mode constant voltage and constant current outputs. ELG-200-48 accepts 100~300VAC input and offers an output voltage of 48V. With a high efficiency of 93% and a fanless design, ELG-200-48 can operate between -40C to 90C under free air convection. The design of the metal housing and IP67 ingress protection level allows the unit to fit both indoor and outdoor applications.

Additional information

Weight 1.2 kg
Voltage (max/rated)

48

Current (amps)

4

Power (watts)

200

R&N (mV)

250

Efficiency (%)

93%

  • Constant Voltage & Constant Current mode output
  • Metal housing design
  • Built-in active PFC function
  • No load / Standby power consumption <0.5W
  • IP67 Design for indoor or outdoor installations
  • Typical lifetime >50000 hours
  • 5 years warranty
  • LED street lighting
  • LED architectural lighting
  • LED bay lighting
  • LED floodlighting
  • Type “HL” for use in Class I, Division 2 hazardous (Classified) location
  • Complies with class II applications
