HLG-600H-54B - 604.8W 54V 11.2A IP67 Rated Dimmable LED Lighting Power Supply

Email

Description

HLG-600H-54B is a 604.8W 54V 11.2A high performance dustproof and waterproof, to IP67 ingress protection rating LED lighting power supply with built-in 3 in 1 dimming function (0~10Vdc, PWM signal, or resistance) and active PFC. Capable of delivering efficiency up to 96% the unit tops the LED power supply field and is able to work at ambient temperatures ranging between -40 and +70C using only free air convection. Other features include surge susceptibility up to 4KV (EN61000-4-5), low no-load power consumption (<0.5Watt) at remote OFF and compliance with harmonic current limitation per EN61000-3-2 Class C (>50% load). These attributes, along with the fully-potted silicone and aluminium case, all make HLG-600H-54B fit for indoor/outdoor LED lighting applications requiring remarkable reliability.

Additional information

Weight 3.9 kg
Voltage (max/rated)

54V

Current (amps)

11A

Power (watts)

605W

R&N (mV)

350mV

Efficiency (%)

96%

  • Universal AC input / Full range (up to 305VAC)
  • Built-in active PFC functio
  • No load power consumption <0.5W at remote OF
  • High efficiency up to 96%
  • -40℃ ~ +70℃ wide operating range
  • Short circuit, over current, over voltage & over temperature protections
  • Fanless design, cooling by free air convection
  • IP67 design for indoor or outdoor installations
  • Withstand 5G vibration test
  • Three in one dimming function - 0~10Vdc or PWM signal or resistive
  • Suitable for dry, damp or wet location
  • 5 years warranty on approved installs
  • LED street lighting
  • LED Highbay lighting
  • Parking space lighting
  • LED searchlight
  • LED fishing lamp
