MEAN WELL Products
DLP-04R - DLP-04R 3.84W 16V 240mA Din Rail Mount Dali Bus Power Supply
DLP-04R is a 3.84W 16V 240mA Din Rail Mount Dali Bus power supply with high efficiency and a small size, supplying 240mA for DALI control gears and DALI devices without power supply circuits.
Description
DLP-04R is a 3.84W 16V 240mA Din Rail Mount Dali Bus power supply with high efficiency and a small size, supplying 240mA for DALI control gears and DALI devices without power supply circuits. The -20~+60C wide temperature operating range can meet all kinds of applications. In addition to powering up to 64 separate DALI dimming power control terminals, DLP-04R can also power the DALI controllers without internal power supply (including DALI panels, DALI groupings, scene controllers) with the rest electricity. In addition, DLP-04R adopts a Din Rail design. DLP-04R complies with EN55015.EN61547.EN61000-3-2, 3 and DALI standard IEC62386-101. It accepts universal input from 90 to 264VAC, and is certified to Class II with no FG and IP20 grade, providing perfect solutions for DALI control system.
Additional information
| Weight | 0.09 kg |
|---|---|
| Current (amps) | 240mA |
| Power (watts) | 3.84W |
| R&N (mV) | 50mV |
| Type | AC/DC,LED Driver,DIN Rail |
| Voltage (max/rated) | 16VDC |
| Range Power | |
| Outputs | Single |
