XBG-240 - XBG-240 240W Constant Power Mode LED Driver

XBG-240 Series is a 240W AC/DC LED driver featuring the constant power mode. XBG-240 operates from 100~305VAC and offers different rated current, 93% efficiency and is suitable for a wide range of internal and external applications.

Email
SKU: XBG-240 Category: Category:

Description

XBG-240 Series is a 240W AC/DC LED driver featuring the constant power mode.XBG-240 operates from 100~305VAC and offers different rated current ranging between 4000mA and 5700mA. Thanks to the high efficiency of up to 93%, with the fan-less design, the entire series is able to operate for -40°C~+90°C case temperature under free air convection.The metal housing design and IP67 ingress protection level allows this series to fit both indoor and outdoor applications. Moreover, the innovative, environment-adaptive capability allows this series to reliably light LEDs for all kinds of applications.XGB-240 Series complies with the latest version of IEC61347/IEC60598-1 and UL8750 international safety regulations.The output and dimming circuit are also completely in accordance with the new regulations regarding isolation to ensure the safety of both users and luminaire system during installation. For more information and to discuss your requirements, please contact a member of our team.

Additional information

Current (amps)

4900mA

Efficiency (%)

93%

Function

3 in 1 Dimming

Inputs

100 ~ 305VAC

Power (watts)

240W

Technology

Unregulated

Type

AC/DC,Constant Power,Enclosed,LED Driver
