HomeMEAN WELL ProductsLED Power SupplyLPV-100-48 100.8W 48V 2.1A Single Output AC-DC Enclosed Power Supply

LPV-100-48 - LPV-100-48 100.8W 48V 2.1A Single Output AC-DC Enclosed Power Supply

100.8W 48V 2.1A Single Output AC-DC Enclosed Power Supply

Email
SKU: LPV-100-48 Category: Category:

Description

PUC-V10M is a 100.8W 48V 2.1A IP67 Rated LED Lighting Power Supply with Active PFC Function and input range of 90V ~ 264VAC. This LED lighting power supply features short circuit, over current and over voltage protections. The unit also has a fully isolated case that is rated at IP67 level to protect against ingress of dust & water splashing against the enclosure from any direction.

Additional information

Weight 0.63 kg
Current (amps)

2.1A

Efficiency (%)

89%

Inputs

90 ~ 264VAC

IP rating

IP67

Power (watts)

101W,100.8W

R&N (mV)

150mV

Standards

Double Insulation

Type

AC/DC,Constant Voltage,LED Driver

Voltage (max/rated)

48VDC

Range Power

Outputs

Single
