HLG-40H-20B - HLG-40H-20B 40W 20V 2A IP67 Rated PFC LED Lighting Power Supply with Dimming Function
40W 20V 2A IP67 Rated PFC LED Lighting Power Supply with Dimming Function
Description
HLH-40H-B Series are a range of single output LED lighting power supplies with wide range input of 90~305VAC (meets 277VAC requirements in North America), built in active PFC function and Three in one dimming function (1~10Vdc or PWM signal or resistance). These LED power supplies are aluminium cased and potted by glue, to comply with IP67 requirements, have adjustable output voltage and current and have high efficiency up to 91%.
Additional information
| Weight | 0.73 kg |
|---|---|
| Current (amps) | 2A |
| Efficiency (%) | 88% |
| Function | Dimmable |
| Power (watts) | 40W |
| R&N (mV) | 150mV |
| Type | AC/DC,Constant Current,Constant Voltage,LED Driver |
| Voltage (max/rated) | 20VDC |
| Range Power | |
| Outputs | Single |
